Specifications
- Supply – 415 V AC,50 hz (P-P), additional auxiliary supply not required .
- Display – 4 digit 7 segment LED Display
- Mounting – Door Mounting
- Operating Temperature – 0°C – 50°C
- Operating Humidity – 10% – 95%
- Dimension 96 x 96 mm
Indication
Under Voltage, Over Voltage, Relay On, Unbalance Voltage, Reverse Phasing & single phasing
- All parameters like low voltage, high voltage, low current high current, unbalanced voltage are site settable
- On Delay and trip delay are site settable
- Micro controller based technology hence reliable and precise
- Parameter value as well as fault message displayed in scrolling manner
